This is a stunning addition for any bathroom, offering discreet support by the toilet, providing easy accessibility without sacrificing design and decor. This elegant design can support up to 500 pounds of weight when secured to mounting structures, making it an ideal and attractive safety accessory for any bathroom.
- User Weight Capacity
- Supports up to 500lbs / 227kgs when installed to structural wood backing.
- Discreet wall stems with concealed screws
- Makes mounting areas virtually invisible.
- Multi-contact wall support
- 4 points of contact for maximum structural support.
|Finish/Colour||Polished Chrome (-CP)
Brushed Stainless (-BS)
Powder Coat Bronze (-ORB)
|Weight Capacity||500lbs / 227kgs (ADA Compliant)
Note: Reduced weight capacity if installed using hollow wall anchors.
|Rail Diameter||1.25" / 31.8mm (ADA Compliant)|
|Wall Clearance||1.50" / 38.1mm (ADA Compliant)|
|Rail Width||7.25" / 184mm|
|Rail Height||13" / 330mm|
|Installation Mechanism||Must screw to wood backing behind wall. Hollow wall anchors can be used when partial wood structure is available (Note: Reduced weight capacity).|
|Installation Hardware/Fasteners||Full Structure: #10 x 3"/76mm length, stainless steel wood screw (x1) and #10 x 2"/51mm length, stainless steel wood screw (x3).
Partial Structure: #10 x 3"/76mm length, stainless steel wood screw (x1) and #10 x 2"/51mm length, stainless steel wood screw (x1) and 3/16-24 x 3"/76mm length, stainless steel bolt and hollow wall anchors (x2).
|Fasteners Exposed or Concealed||Concealed; Rail stems conceal mounting hardware + Plastic caps (x3).|
|Country of Origin||China|
|Shipping Dimensions||14x9x4" / 356x229x102mm|
|Shipping Weight||4lbs / 1.8kgs|
|Warranty||Limited lifetime warranty|
